Projection Of Lines Problems With Solutions Ppt . examples are given of drawing projections of a point and various types of lines (vertical, parallel, inclined) placed in. The other end b is 40 above h.p and 50 in front of v.p. Draw its projections solution steps: the projection of a line can be obtained by projecting its end points on planes of. A line ab of 80 long, has its end a, 15 from both h.p and v.p. the document discusses the concepts and methods of projecting lines in engineering graphics. Line’s tv makes 300 with xy line. 1) draw reference line xy. To find true length & true. 6 projections of straight lines. A point a is 20 mm above hp and 30 mm in front of vp. Information regarding a line means it’s length, position of it’s ends. example problems on points problem 1:
